SNMP Proxy ... wait what?

Working with SNMP in 2025 is still a thing. Most hate it, but it’s sometimes the only thing you can use to get insights into the box you are working with. I want to shed some light on the SNMP proxy capability in Net-SNMP, it might be possible some people haven’t heard of it and might find it useful. In a nutshell, you can use Net-SNMP as a proxy to query information from another SNMP agent over an IP connection you can’t or do not want to query directly.

Hackathon on BGP monitoring using BMP in OpenNMS

We have seen people in the OpenNMS chat who started playing with the BGP monitoring protocol. I had some notes in our MediaWiki which doesn’t exist anymore. To provide some background I’ve resurrected my notes and republished the content. I had to tweak a few places to make it a bit more current. During the 5 years, OpenNMS has fixed bugs and maintained the functionality. The main intention of resurrecting the article is to give people some insights and background on what approach was chosen and why things are as they are today.

Building container images for OpenNMS

The previous article described how you can build and compile OpenNMS Horizon from source. This section explains how you build container images (OCI) from the source artifacts.

Deploy base image as foundation

Running OpenNMS Horizon core, Minion, or Sentinels in a container requires shared components. Some of them are a) the JDK base image, b) some useful tools, and c) JICMP, and JICMP6.

The JDK is shared with Core, Minion, and Sentinel. JICMP, and JICMP6 are required for Core and Minion. To manage these dependencies, we have a deploy-base image created which covers the main requirements running the Core, Minion, and Sentinel server processes. Getting an efficient size was a goal and a multi-stage build approach was chosen to address it. The fist

Dealing with secrets in OpenNMS Horizon

Dealing with secrets in a monitoring platform is a tedious task. The nature of monitoring systems is providing integrations in as many systems. Here is my mental model looking at the various ways for integrating OpenNMS. Especially having a 20 year old platform gives you some very own challenges. Talking about integration of monitoring systems, In OpenNMS Horizon/Meridian (OpenNMS for short), are some places where you have just one option, and some with various options. This article should help you to get an idea where you need to deal with secrets and credentials. The north/south areas serve monitoring purpose whereas the west/east directions address scaling topics in the context of volume, geographic or feature sets.

OpenNMS Horizon with RRDtool

As described in the previous article we have built and installed an OpenNMS Horizon Core component from the source. It comes with a Java implementation of RRDTool called JRobin. The portability of Java applications allowed users to run OpenNMS platforms where RRDTool wasn’t easily available. It was threadsafe and allowed more threads writing data. RRDTool implemented that functionality and surpassed JRobin performance and feature wise.

💁‍♀️ If you just don’t care in a dev or testing environment, you can use JRobin for simplicity, because it’s just there and works out of the box. For any production environment, I highly recommend to use RRDTool. It gives you much better support for tools, performance and features. Migrating later is doable but painful.

Demystifying iplike in OpenNMS Horizon

As described in the previous article we have built and installed an OpenNMS Horizon Core component from the source.

With setting up the database schema with ${OPENNMS_HOME}/bin/install -dis a function IPLIKE is created for the OpenNMS database.

It allows us to get IP address matches for IPv4 and IPv6 addresses with filters used in all IP filters in the tool, e.g. IPADDR IPLIKE 192.168.0-3.0-255.

By default, the function is implemented in a SQL procedural language (PL/pgSQL). As OpenNMS had to deal with larger IP address inventories, an optimized version in C was created which is available as the IPLIKE package. The C version of this stored procedure has to be built against header files from specific PostgreSQL major versions. This is the reason you see iplike-pgsql{12,13,14,15} packages in the OpenNMS repositories.

JniPing vs. JnaPing

As described in the previous article we have build an OpenNMS Horizon Core component from source. If you don’t do anything else, it will uses an ICMP implementation using Java Native Access (JNA). The big benefit here, it’s all Java and supports IPv4 and IPv6. You also don’t need additional permissions on your Linux system such as net.ipv4.ping_group_range and SELinux. It makes it perfect for local development and also if you want to run OpenNMS on exotic architectures where you can’t easily compile or build the JNI equivalent written in C from the source code. The downside it comes with some overhead for each ICMP service test. You can see the effect on the latency measurements, especially on very fast responding IP addresses, such as the local loopack interface.

OpenNMS - Auf die harte Tour

I asked many questions in 2004 on IRC when I tried to get my first OpenNMS instance up and running. People in the community held my hand when I was struggling. They helped me to get to my personal “Aha!” moments. If you have time and patience, this is great, because this is a great learning opportunity. In the world of User Experience Design, this is called “friction”. How can you determine friction? My background is that of someone who cut his hands on sharp metal changing network equipment and operating IT gear for others – I have empathy for people running OpenNMS. I like to run user empathy sessions with someone in your target group and figure out where and how they struggle. If you have no one, the next best option is to put yourself in the shoes and get your hands dirty.

BGP monitoring playground

Monitoring BGP can be done in various ways. First thing people want to know is if there is a way to get notifications in case a BGP peering session goes down. A pretty common way monitoring the BGP peering session state is using SNMP and the RFC1269 MIB. In OpenNMS Horizon we have the BGP session monitor which allows to track the state using the BGP peer table. The downside is, you need to configure for every peering session a monitor and this can be cumbersome and hard to maintain.

OpenNMS Horizon, Docker, Traefik and Let's Encrypt

I work from home for over 6 years now and especially when you like networking, want to get stuff up and running and breaking it - you start looking around :) You’ve heard about k8s, k{0,3}s or Microk8s but you don’t want to use it to run your private blog and you find yourself in a spot where the benefits running stuff in containers justify the pain - this article might be something for you :)
